HDMI Optical Fiber Extender 4K30Hz With KVM Function|ND8210HFUK-4K30
HDMI Optical Fiber Extender 4K30Hz With KVM Function | suppliers | Newbridge
Newbridge mainly a manufacturer of HDMI Optical Fiber Extender 4K30Hz With KVM Function wholesale
FEATURES
Transmits HDMI video OM3 transmission 300 meter multi mode dual core optical fibe；
Support keyboard and mouse signal transmission ；
Support video resolution up to 3840*2160@30Hz, 1920*1200@60hz, 1920*1080P@60Hz, 3D signal；
Transmits HDMI signals up to 300 meters over OM3 fiber optic cable, also support EDID and HDCP；
Compliance with HDMI I 1.4 standard；
High compatibility, can auto-match source and display device；
Built-in automatic adjustment system, make the image smooth, clear and stable;
Built-in ESD protection system;
Simple to install, plug and play;
Newbridge®The HDMI Fiber optic extender provides extension of HDMI and 3D signals long distances over one fiber optic cable, it supports high resolution up to 4K*2K, And at the same time support USB keyboard mouse long distance transmission function, EDID pass-thru function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.
Parameter | Description | |
Video | Standards | HDMI 1.4 |
Maximum pixel clock | 225MHz | |
Maximum data rate | 6.75Gbps | |
Resolution range | Up to 3840*2160@30Hz | |
Connector | Female HDMI type A | |
Impedance | 100Ω | |
K/M | Interface | PC: MINI-USB Keyboard And Mouse: USB-A |
Optical fiber | Interface | SFP model – LC connector |
Fiber type | Multi mode dual core | |
Wavelength | Multi mode optical fiber 850 nm | |
Interface bandwidth | 10Gbps | |
Transmission distance | Double OM3 fiber: 300M(Support HDCP | |
Other | Power supply | The power adapter: DC 5V/2A |
Power dissipation | MAX 5W | |
Temperature | Operating: -5℃ ~ +70℃ | |
Humidity | Operating: 5% ~ 90% | |
Dimension | 93*70*25mm | |
The warranty | 1 year free warranty | |
Panel |
Port name | Description |
HDMI IN/OUT | HDMI signal input/output |
EDID | EDID Copy button, Press 3 seconds, copy EDID from HDMI IN display device to system .If HDMI IN interface no display connect, restore default EDID. |
KM | PC: MINI-USB Keyboard And Mouse: USB-A |
DC/5V | Power adapter socket |
FIBER | SFP model --- LC connector |
LED indicator | Description |
LINK | Optical fiber signal connection indicator |
STA | Video signal connection indicator |
POWER | System power indicator |
Ordering Models
HDMI Optical Fiber Extender 4K30Hz With KVM Function|ND8210HFUK-4K30
Shipping & Lead Time
Sample Order: 1-3 business days via DHL/FedEx/UPS.
Bulk Order: 7-15 business days depending on quantity.
OEM/ODM: 25-35 business days including custom packaging.
MOQ: 10 units for standard models; 100 units for OEM branding.
Port: FOB Shenzhen / Hong Kong.
