8 Port 10/100/1000Mbps|ND-IGS2208P Web-Managed Industrial PoE Switch
8 Port Web-Managed Industrial PoE Switch
Newbridge 10/100/1000M 8 Port Web-Managed Industrial PoE Switch manufactured by Newbridge, long service life
FEATURES
Full Gigabit Ethernet ports
IEEE 802 .3af/at PoE standards
Support Port Isolation
Support 802. 1q VLAN
Support Port Mirroring
Support Port-Based/802. 1p/DSCP priority QoS
Support Storm Control
Web-based user interface
Three Redundant 12/24/48 VDC power inputs
-40 to 75 °C wide operating temperature range
DIN-rail mounting
The NB-IGS2208P is a full Gigabit managed industrial PoE switch independently developed by Newbridge, with 8* 10/ 100/ 1000M PoE ports , ports 1-8 can support IEEE 802.3af/at standard PoE power supply, single-port PoE power of up to 30W, and all the ports support full wire speed forwarding. This POE switch is designed to meet the needs of industrial fields and systems, and can operate stably for a long time in harsh environments. It is suitable for intelligent transport, rail transit, power industry, mining metallurgy, green energy construction and other fields.
NB-IGS2208P supports WEB management, supports a variety of ring network protocol STP/RSTP (<50ms) to improve link backup and network reliability, It can achieve security network topology management, link aggregation, port management, port mirroring and remote operation and maintenance. with fast switching function and multiple access ports, suitable for accessing LAN equipment of various scales. IP30 protection level, three redundant power sup- plies, low-power fanless cooling technology, MTBF up to 10 years, 3-year warranty, Suitable for intelligent transportation, rail transportation, power industry, mining, oil, shipping, metallurgy and green energy construction and other industrial scenarios to set up a cost-effective, stable and reliable communication network.
Model | NB-IGS2208P | |
Interface | 8 * 10/ 100/ 1000Base-T PoE ports (Data/Power) 2 sets of V+, V- redundant DC power interface (6 Pin Phoenix terminal) 1 group of alarm output and relay output can define various custom condition trigger. | |
PoE Port | Port 1-8can support IEEE802.3af/at POE standard | |
Network Protocol | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX/ FX; IEEE802.3ab 1000Base-TX IEEE802.3z 1000Base-X | |
PoE Standard | IEEE802.3af/at | |
Ethernet Port Feature | 10/ 100/ 1000BaseT (X) automatic detection, full / half duplex MDI/MDI-X adaptive | |
6Forwarding Mode | Store and Forward(Full Wire Speed) | |
Switching Capacity | 12Gbps | |
Forwarding Rate@64byte | 11.904Mpps | |
MAC | 8K | |
Buffer Memory | 4M | |
Twisted Pair Transmission | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-T: Cat5 or later UTP(≤100 meter) | |
Power Supply Pin | Only support 1/2 (+), 3/6 (-) 4-core power supply | |
Max / Average Power Per Port | 30W/30W | |
Total PWR /Input Voltage | 240W (50-57VDC) | |
Power Consumption | Standby:<10W;Full load:<240W | |
LED | System indicator:SYS(green); Network Indicator: Link (yellow); SFP Indicator: L/A (green) ; PoE Indicator: PoE (green) | |
Port Management | -Support port status display -Support port traffic statistics -Support port duplex/negotiation rate configuration -Support IEEE802.3x flow control configuration (full duplex) -Supports EEE energy saving and Green Ethernet features |
VLAN | Supports port-based IEEE802.1QLAN configuration |
Port aggregation | Supports static aggregation |
loop protection | Support loop protection function, support anti-loop function |
Multicast | Supports IGPSnoopingv1/v2 and up to 256 multicast groups. |
mirroring | Supports mirroring in the base port stream |
Qos | Supports Diff-Serv Qos Supports 8 output queues per port Supports 802.1p/ DSCP priority mapping Supports Priority Mark/Remark |
Safety features | Supports broadcast storm suppression Support port speed limit Support port isolation |
DHCF | Supports DHCP Snooping |
Management | Support WEB Managed(HTTPS) Support one-click restore |
