8 port 100/1000Mbps Ethernet Switch 5V1AND-921-08TX

 Click on the picture to enter the Gallery

FEATURES

Provide 8 10/100/1000M adaptive RJ45 ports

All ports can achieve wire-speed forwarding;

Plastic body, small and exquisite

LED dynamic indicators for easy status indication and troubleshooting

Support port automatic flip, more convenient to use

Support MAC address self-learning

Newbridge® The ND-921-08TX 8-port 10/100/1000M unmanaged switch allows you to quickly, reliably and efficiently build wired networks in your home or office. The switch is designed to enhance the performance of small workgroups while providing network flexibility. The device is easy to use, users only need to connect the device to any port via a network cable.

The ND-921-08TX can be connected to multiple computers for file sharing. Share your internet connection by connecting it to your router.

ND-921-08TX does not use wind Fan, can work quietly, so that you can watch streaming media from the network and browse the web quietly.

The ND-921-08TX is a plug and play device. Easily connect multiple computers with no configuration required for file, music and video sharing on a home or small office network. When the port's buffer is full, the 802.3x flow control feature minimizes packet loss, providing a more reliable data transfer connection for connected devices.

ND-921-08TX can adapt to 10/100/1000Mbps ports. Each port has LED indicators to indicate link connectivity and activity. These ports can detect network speed and auto-negotiate between 10BASE-T and 1000BASE-TX, as well as full-duplex and half-duplex, to provide the best possible network speed for every device connected to the network.

The ND-921-08TX also supports automatic MDI/MDIX recognition, allowing you to use regular pass-through twisted pair cable to connect each port to a server, hub, router or other switch

Product Name

8 Port 10/ 100/ 1000M Fast Ethernet switch

Product Model

ND-921-08TX

Interface

8x 10/ 100/ 1000Base-T ports



Network Protocols

IEEE802.3 10BASE-T IEEE802.3i 10Base-T IEEE802.3u 100Base-TX

IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-X


IEEE802.3

Network Media

10BASE-T: Cat3,4,5 UTP

100BASE-TX: Cat5 or later UTP  1000BASE-TX: Cat5 or later UTP



Performance Specification

Bandwidth: 16Gbps

Packet Buffer Memory: 1Mbits

10 Mbps Packet Forwarding Rate14880 pps/port

100Mbps Packet Forwarfding Rate:148800 pps/port

MAC Address Table: 2K

Switching Delay: <10us

Forwarding Mode

Store-and-Forward

LED Indicators

Power: PWR; Link: Link/Act

Power Supply

Input Power: 5V/1A DC

Working Consumption    : <1W



Working Environment

Working temperature: 0+40 ;

Storage temperature: -40+70

Relative Humidity: 5%~90 %( no condensation)



Packing List

Industrial 5-port Fast Ethernet Switch

 User Manual/Certificate of quality/Warranty card

 Power Adapter

MTBF

300,000 hours
